Hoists
SINGLE EC600 ECP1500 NOV2032 SC2032F
Maximum Lifting Height (anchored) 120m 150m 345m 300m
Maximum Payload 600kg 1500kg 2000kg/ 20 pers. 2000kg/ 24 pers.
Elevation Speed 20m/min 24m/min 35m/min 36m/min
Maximum Distance Between Standard Ties 6m 6m 12m 21m
Lifting Cage/ Transport Basket Dimensions
Internal (LxWxH)
1.5m x 1.1m x 1.0m 3.6m x 1.3m x 1.1m 3.2m x 1.5m x 2.5m 3.2m x 1.5m x 2.1m
Ground Station Dimensions (LxWxH) 4.0m x 3.0m x 2.0m 4.0m x 3.0m x 2.0m 3.6m x 2.7m x 3.0m 3.9m x 2.6m x 2.7m
Transport Basket Gate Openings (W) 1.5m loading/
1.1m unloading
1.3m loading/
unloading
- -
Lifting Cage Door Opening Dimensions (WxH) - - 1.5m x 2.0m 1.5m x 2.1m
Landing Gates Opening Dimensions (WxH) 1.1m x 2.0m 1.6m x 2.0m 1.6m x 2.0m 1.6m x 2.0m
Power Supply 3 phase 400v 50Hz 3 phase 400v 50Hz 3 phase (earth & neutral)
400v 50Hz
3 phase (earth &
neutral) 400v 50Hz
Power Supply Fuses/ RCD Protection (minimum) 32A/300ma
motorised
63A/300ma
motorised
100A (time lag slow fuse)/
30ma motorised
63A (slow)/
500ma motorised
Power Supply Socket 32A 5 pin 32A 5 pin - -
Starting Current 28.4A 76A 300A 86A
Power Consumption 6kW/ 6.6kVA 16kW/17.6kVA 35.45kW/ 39kVA 22.5kW/ 24.75kVA
TWIN EC600 ECP1500 NOV2032 SC2032F
Maximum Lifting Height (anchored) - - 345m 220m
Maximum Payload (per lifting cage) - - 2000kg/20 pers. 2000kg/24 pers
Elevation Speed - - 35m/min 36m/min
Maximum Distance Between Standard Ties - - 12m 21m
Lifting Cage Door Opening Dimensions (WxH) - - 3.2m x 1.5m x 2.5m 3.2m x 1.5m x 2.1m
Ground Station Dimensions (WxH) - - 3.6m x 4.6m x 3.0m 3.9m x 5.0m x 2.7m
Transport Basket Gate Openings (W) - - - -
Lifting Cage Door Opening Dimensions (WxH) - - 1.5m x 2.0m 1.5m x 2.1m
Landing Gates Opening Dimensions (WxH) - - 1.6m x 2.0m 1.6m x 2.0m
Power Supply - - 3 phase (earth & neutral)
400v 50Hz
3 phase (earth &
neutral) 400v 50Hz
Power Supply Fuses/RCD Protection (minimum) - - 100A (time lag slow fuse)
/ 30ma motorised
63A (slow)/ 500ma
motorised
Power Supply Socket - - - -
Starting Current (per lifting cage) - - 300A 86A
Power Consumption (per lifting cage) - - 35.45kW/39kVA 22.5kW/ 24.75kVA
HOIST - Specifications
