Mastclimbers Light Duty Medium Duty Heavy Duty
SINGLE 3000 ACT 4 4000 5000 ACT 8 8000
Maximum Lifting Height (anchored) 120m 168m 100m 100m 168m 150m
Maximum Lifting Height (free standing) 6m 18.3m 15m 20m 13.7m 15m
Maximum Platform Length 11.84m 14.2m 13.75m 16.9m 17.3m 16.9m
Maximum Payload 1700kg 1820kg 2000kg 2700kg 3635kg 4500kg
Elevation Speed 10m/min 5.2m/min 6m/min 7m/min 11.6m/min 7.2m/min
Maximum Distance Between Standard Ties 9m 12.2m 18.5m 18.5m 9.1m 18m
Power Supply 3 phase 400v
50Hz
3 phase 400v
50Hz
3 phase 400v
50Hz
3 phase
400v
50Hz
Diesel 3 phase
400v
50Hz
Power Supply Fuses/RCD Protection (minimum) 32A/ 300ma
motorised
32A/ 300ma
motorised
32A/
300ma
motorised
32A/
300ma
motorised
32A/
300ma
motorised
Power Supply Socket 32A 5 pin 32A 5 pin 32A 5 pin 32A 5 pin 32A 5 pin
Starting Current 29A 61.8A 60A 60A 60A
Power Consumption 6kW/ 6.6kVA 11kW/
12.1kVA
7.27kW/
8kVA
7.27kW/
8kVA
7.27kW/
8kVA
TWIN 3000 ACT 4 4000 5000 ACT 8 8000
Maximum Lifting Height (anchored) 120m 168m 100m 100m 168m 150m
Maximum Lifting Height (free standing) 6m 18.3m 15m 20m 13.7m 15m
Maximum Platform Length 32.4m 33.2m 31.4m 40.6m 38.1m 46.2m
Maximum Payload 3420kg 3635kg 4200kg 5000kg 7275kg 8000kg
Elevation Speed 10m/min 5.2m/min 6m/min 7m/min 11.6m/min 7.2m/min
Maximum Distance Between Standard Ties 9m 12.2m 18.5m 18.5m 9.1m 18m
Power Supply 3 phase 400v
50Hz
3 phase 400v
50Hz
3 phase 400v
50Hz
3 phase
400v
50Hz
Diesel 3 phase
400v
50Hz
Power Supply Fuses/RCD Protection (minimum) 32A/ 300ma
motorised
32A/ 300ma
motorised
32A/ 300ma
motorised
32A/ 300ma
motorised
32A/
300ma
motorised
Power Supply Socket *per drive unit 32A 5 pin 32A 5 pin* 32A 5 pin* 32A 5 pin* 32A 5 pin*
Starting Current *per drive unit 58A 61.8A* 60A* 60A* 60A*
Power Consumption
*per drive unit
12kW/
13.2kVA
11kW/
12.1kVA*
7.27kW/
8kVA*
7.27kW/
8kVA*
7.27kW/
8kVA*
MCWP - Specifications
PLEASE NOTE - Individual Specification Sheets can be obtained on any of the Mastclimbers and Hoists listed above and to
the right by emailing
