Steel Loading Bays
Steel loading bays can be installed individually
or as vertical series of loading bays to multiple
floors. We have a partnership agreement with
Xena Systems to be the sole provider of their
platforms and cranes to the Irish market.
Our range of platforms include:
Standard Platform
Suitable for general applications where
retractability is not required and has a SWL of
up to 5 tonnes.
Rolling Platform
Where simultaneous access to several levels
from one lifting point is required, rolling
platforms are a solution. The platforms are
vertically stacked and can be rolled back to
the building line to allow crane access to the
required platform.
Underslung Platform
Where retractability is not required and there
is a need for level loading at the slab edge, an
underslung platform provides a 5 tonne SWL.
X12 Crane
This floor mounted crane is designed to reduce
dependence on tower cranes, supplying one
platform or a stack of rolling platforms. It has a
lifting capacity of 2 tonnes and can be used in
lift shafts and tunnels where conventional cranes
cannot normally be used.
Hoists and Transport Platforms
Our range of hoists and transport platforms
range from a small, compact unit suitable for
use in confined spaces such as lift shafts, up
to our largest hoist capable of transporting
2000kg of goods or 24 personnel. Features of
our hoists include large payloads, cage sizes
suitable for taking palleted goods and side and
end loading options.
We provide an induction for the end user
together with a manual.
SC2032F Goods and Personnel Hoist
Our largest hoist, it has a payload of either
2000kg or 24 personnel. It has a lifting speed
of 36m with a large cage size of up to 3.2m x
1.5m. A side loading door is also an option.
EC600 Goods Hoist
Our most compact hoist which can be installed
into most lift shafts, and takes a payload of
600kg.
ECP1500 Transport Platform
This can be used as a goods hoist with speed
of 24m/min or as a transport platform with a
speed of 12m/min (with roof installed). The
payload is 1500kg.
Model
Goods
Personnel
Max Lifting
Speed (m/min)
Max Payload
(kg)
Max Height
(m)
Max Cage
Dimensions
(l x w) (m)
SC2032F
Yes
Yes (up to 24) 36
2000
300
3.2 x 1.5
EC600
Yes
No
29
600
120
1.6 x 1.1
ECP1500 Yes
Yes (up to 7)
Goods: 24
Personnel: 12
1500
150
3.4 x 1.4
EC1700
Yes
No
20
1700
150
1.75 x 1.8
Hoists
EC1700 Goods Hoist
Similar to the EC1500 but larger and with a
bigger payload, it can be fitted with a basket
suitable for taking plasterboard sheets and other
large items.
SC2032F H
oist
